1.511.1301.14
SM-NIPPEL SLANG, SVART, PG13.5.5, SLANG NW14
1.511.1301.14
- Availability:
-
Yes
- Total: 1
Related items
SM-N, rak snabbkoppling
Rak snabbmontage av spiralslang
Material: Polyamid
Skyddsklass: IP 54, vid användning av O-ring. Med O-ring och fast montage IP 65
Drifttemperatur kontinuerligt: -20º C till +80º C
Färger: Grå RAL 7031, Svart RAL 9005
- Total: 1
Product Properties
| Revolving thread | No |
|---|---|
| Thread material | Polyamide (PA) |
| Degree of protection (IP) | IP54 |
| Model | Straight |
| Type of connection | Snap connection |
| Thread type | Other |
| Construction type | External thread |
| Colour | Black |
| Operating temperature | -20-80 °C |
| Material | Polyamide (PA) |
Dimensions
| Nominal diameter | 14 mm |
|---|---|
| Thread connection size | PG13.5 |
| Total height | 24 mm |
| Max. outer diameter hose | 26.5 mm |
| MOQ | 50 . |
| Unit | pcs |
| Total length | 37 mm |
| Thread length | 9 mm |
Logistics
| Barcode | |
|---|---|
| Country of origin | DE |
| Item status | Non Stock Item, can be on stock but is not a regular stock item. |
| MOQ | 50 . |
| Stock code | 1.511.1301.14 |
| Taric code | 85389099 |
| Unit | pcs |
Approvals
| Approved in combination with protective conduit CSA | No |
|---|---|
| Approved in combination with protective conduit UR | No |
| Approved in combination with protective conduit VD TÜV/GGVS | No |
| Approved in combination with protective conduit DIN EN 61386-23 | No |
| Approved in combination with protective conduit Lloyd's Register | No |
| Degree of protection (IP) | IP54 |
Other info
| ETIM-Class | EC001176 - Screw connection for corrugated plastic hose |
|---|---|
| ETIM-Release | 7.0 |
| Product Group | Fittings for plastic conduit |
| Alternative SKU | 1.511.1301.14 |
Compliance
| RoHS | RoHS 3 (2015/863) |
|---|
