- Total: 6
K 6
K 6_VP
With return feather for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 1.5-6.0 mm²
Type of crimping: Thorn crimp
Length: 150 mm
Crimps end-sleeves:
Single end-sleeve: 1.5-6.0 mm²
Type of crimping: Thorn crimp
Length: 150 mm
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
K 48
K 48_VP
With return spring for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 0.25-2.5 mm²
Type of crimping: Trapezoid crimp
Length: 150 mm
Crimps end-sleeves:
Single end-sleeve: 0.25-2.5 mm²
Type of crimping: Trapezoid crimp
Length: 150 mm
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Trapezoid compression
K 4
K 4_VP
With return feather for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 0.5-2.5 mm²
Type of crimping: Thorn crimp
Length: 150 mm
Crimps end-sleeves:
Single end-sleeve: 0.5-2.5 mm²
Type of crimping: Thorn crimp
Length: 150 mm
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- Yes
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves
- Compression shape:
- Arbour clamping
Coaxial connectors
1089014
22543157
Crimping coaxial for Huber & Suhner coaxial connectors.
Large tool without dies.
Crimping coaxial for Huber & Suhner coaxial connectors.
Large tool without dies.
- With locking device (for mechanical tools):
- Yes
- Inserts exchangeable:
- Yes
- Number of included inserts:
- 0 .
- With automatic return:
- Yes
- Cycle time:
- 3 s
- Suitable for:
- Screen connector
- Construction/operation:
- Mechanical
- For component:
- Coaxial
- Compression shape:
- Hexagon
EAP 130
EAP 130_VP
With return spring for quicker handling.
Crimps end-sleeves:
Single end-sleeve: 0.75-10.0 mm²
Twin end-sleeves: 0.5-6.0 mm²
Type of crimping: Thorn crimp
Length: 180 mm
Crimps end-sleeves:
Single end-sleeve: 0.75-10.0 mm²
Twin end-sleeves: 0.5-6.0 mm²
Type of crimping: Thorn crimp
Length: 180 mm
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves, End sleeve, Twin, Ändhylsor, Twin
- Compression shape:
- Arbour clamping
EAP 120
EAP 120_VP
With return spring for quicker handling.
Front crimping.
Crimps end-sleeves:
Single end-sleeve: 0.25-2.5 mm² and 4.0-6.0 mm²
Twin end-sleeves: 0.5-4.0 mm²
Type of crimping: Trapezoid crimp
Length: 180 mm
Front crimping.
Crimps end-sleeves:
Single end-sleeve: 0.25-2.5 mm² and 4.0-6.0 mm²
Twin end-sleeves: 0.5-4.0 mm²
Type of crimping: Trapezoid crimp
Length: 180 mm
- Number of crimps:
- 1
- With locking device (for mechanical tools):
- No
- Inserts exchangeable:
- No
- Number of included inserts:
- 1 .
- With automatic return:
- No
- Cycle time:
- 2 s
- Suitable for:
- Cable end sleeves
- Construction/operation:
- Mechanical
- For component:
- End sleeves, End sleeve, Twin, Ändhylsor, Twin
- Compression shape:
- Trapezoid compression
- Total: 6
