För Mega L-säkringar med lock. Säkringen skruvas fast med 2 stycken M8 muttrar. Hållaren fästs med 2 bultar. Maximal kabeldiameter: 25 mm OBS! Säkring ingår ej.

För 2 stycken Mega L-säkringar med lock. Säkringen skruvas fast med 2 stycken M8 muttrar. Hållaren fästs med 4 bultar. Maximal kabeldiameter: 25 mm OBS! Säkring ingår ej.

För Midisäkringar i nylon, 1-20 Amp.

Rörkabelskor 2-håls, KRD. För fåtrådig kabel (klass 2). Material: 99.9% ren Cu Ytbehandling: > 4µ Sn Märkning på rörkabelskons platta kan t.ex. vara: n35-12D n = Nemiq // 35 = 35 mm² kabel // 12 = M12 hål // D = KRD // F = KRF // T = KRT Märkning på rörkabelskons hals kan t.ex. vara: 13 13 = Ytterdiameter på halsen (OD-måttet). Vid pressning med 6-kantsbackar skall halsmärkning och backmärkning överensstämma.

Copper tube lugs for stranded (class 5 and class 6) and solid wires (class 2). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12F n = nemiq // 35 = 35 wire // 12 = M12 stud size. // F = KRF, D= KRD, T = KRT Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

Copper tube lugs for stranded (class 5) and solid wires (class 2). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12T n = nemiq // 35 = 35 wire // 12 = M12 stud size. // T = KRT, F = KRF, D= KRD Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

Copper tube lugs for stranded (class 5 and class 6) and solid wires (class 2). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12F n = nemiq // 35 = 35 wire // 12 = M12 stud size. // F = KRF, D= KRD ,T = KRT Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

Copper tube lugs for stranded (class 5) and solid wires (class 2). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12T n = nemiq // 35 = 35 wire // 12 = M12 stud size. // T = KRT, F = KRF, D = KRD Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

For stranded wires (class 5 and class 6). Material: 99.9% pure copper Surface: > 4µ Sn Inscriptions on the lugs palm can for ie be: n35-12F n = nemiq // 35 = 35 wire // 12 = M12 stud size. // F = KRF, D= KRD, T = KRT Inscriptions on the lugs neck can for ie be: 13 13 = Outside diameter of the neck (OD). When crimping with hexagon dies neck inscription and die markings must conform.

H1Z272-K solar cell connection cable offers an optimal solution when it comes to connecting solar panels to each other or with junction boxes and frequency converters. The cable is very resistant to mechanical impact. Good properties in terms of temperature range, chemical resistance, UV resistance and short-circuit resistance. The cable is halogen free. Construction: Conductor: Tinned copper according to IEC 60228 class 5 Conductor insulation: Inner sheath: POLYOLEFIN Outer sheath: POLYOLEFIN Coat color: See product facts Technical data: Minimum bending radius: Variable = D < 8 mm² x cable diameter Ø Fixed = D > 8 mm3 x cable diameter Ø Temperature range: -40ºC to + 110ºC Rated voltage: Uo / U AC: 1000V, DC: 1500V Test voltage: 6500VAC Approvals: EN 50575: 2014 EN 50575 / A1: 2016 CE EN 50618 CPR Eca

Flame retardant thermoplastic cable, suitable for vehicles use on low voltage applications and systems, even in hot environments, without direct contact of heat sources on the cable. Heat-resistant cable, suitable for applications inside the engine compartment. Packaging (OD x Hub x Width): Spool B6: 250mm x 56mm x 95mm Construction: Conductor: Annealed multi-wire copper class 3 Leader insulation: XHFFR Coat color: See product data Technical data: 100V Temp. range: -40ºC to + 125ºC Approvals: ISO 6722 class C

Flame retardant thermoplastic cable, suitable for vehicles use on low voltage applications and systems, even in hot environments, without direct contact of heat sources on the cable. Heat-resistant cable, suitable for applications inside the engine compartment. Packaging (OD x Hub x Width): Spool B6: 250mm x 56mm x 95mm Construction: Conductor: Annealed multi-wire copper class 3 Leader insulation: XHFFR Sheath color: Black Conductor color: See product data Technical data: 100V Temp. range: -40ºC to + 125ºC Approvals: ISO 6722 class C

Drifttemperatur: -25° C till +120° C

Drifttemperatur: -25 grader C till +100 grader C

Drifttemperatur: -25 grader C till +100 grader Celsius

Drifttemperatur: -25 grader C till +100 grader C Färg: Grå RAL 9005

Drifttemperatur:-25 grader C till +120 grader C

Material: Polyamid 6 Drifttemperatur: -25 grader C till +100 grader C Färg:Grå RAL 7035

Drifttemperatur:-40 grader C till +200 grader C

Drifttemperatur:-25 grader C till +120 grader C

Drifttemperatur:-25 grader C till +120 grader C

Round flexible cable for car and boat applications. Packaging (OD x Hub x Width): Spool B3: 160mm x 56mm x 50mm Spool B4: 160mm x 56mm x 90mm Spool B5: 200mm x 56mm x 88mm Drum Structure Conductor: Blank stranded copper Conductor insulation: PVC Identification line up on conductors: Grey, black, red, blue, yellow, green, brown, white, purple, pink Outer Sheath: PVC Sheath identification: Grey, black, white Technical data: Rating voltage: 60V Temperature range: -25ºC to +70ºC (-13ºF to +158ºF)

Flat flexible connection cable for car and boat applications. Packaging (OD x Hub x Width): Spool B3: 160mm x 56mm x 50mm Spool B4: 160mm x 56mm x 90mm Spool B5: 200mm x 56mm x 88mm Structure Conductor: Blank stranded copper Conductor insulation: PVC Core color (unless otherwise specified): Gray, black Outer Sheath: PVC Sheath Colour: Grey, black Technical data: Rating voltage: 60V Temperature range: -25ºC to +70ºC (-13ºF to +158ºF)

Cable used mainly in motor vehicles as ignition cable. It is built of a multi-wire standard copper conductor and insulation and sheath of standard PVC that can withstand temperature range -25 -C to + 70ºC. Packaging (YD x Hub x Width) Bobin B3: 160mm x 56mm x 50mm Max voltage: 15kV Outer diameter: 5.2mm Structure Conductor: Stranded copper Outer sheath: PVC, double insulated Coat color: Black or Red
